1010 Chip HD LED Display , LED TV Display Board Small Aluminum Cabinet

PASSION LED LIGHTING INTERNATIONAL LIMITED

1010 Chip HD LED Display , LED TV Display Board Small Aluminum Cabinet

Brand Name : PASSION

Model Number : P1.92mm

Certification : CCC , CE , ROHS

Place of Origin : Shenzhen,China

MOQ : Negotiation

Price : Negotiation

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 2000SQM/Month

Delivery Time : 10 - 20 working days

Packaging Details : Export Wooden Case & Flight Case

Gray Scale : 16 Bits

Cabinet Weight : 4.5Kg

Material : Aluminum

Working voltage : AC 100-240V

Pixel Failure : <0.0003

Viewing Angle(H/V) : 140°/140°

Brightness : 800CD/sqm

Name : HD LED Display

Contact Now

1010 Chip HD LED Display , LED TV Display Board Small Aluminum Cabinet


Specifications of HD LED Display:


1) Application: Indoor Fixed

2) Optional of Front service and rear service

3) Silent operation

4) Lightweight and seamless

5) High gray and low brightness

6) High color Fidelity

7) Wide viewing angle

8) Excellent thermal management

9) Low consumption

10) Quick lock system allowing fast rigging

11) Long life span time

12) Shorter Mean time bettwen failure


Spec Details of HD LED Display :


ModelPHD -1.9
Pixel Pitch1.92mm
Pixel Density271232 px/m2
LED TypeSMD1010
LED Configuration1R1G1B
Cabinet Dimension400*300mm
Cabinet Resolution208*156px
Cabinet Weight4.5kg
Cabinet Materialdie-casting
Ingress Protection (front/rear)IP40/IP21
Brightness>800nits
Viewing Angle(H/V)140°/140°
Driving Method1/26 Scan
Power Consumption(avg.)220w/m2
Frame Refresh≥ 60Hz
Data Refresh Rate≥ 1500Hz
Gray Scale16bit
Power SupplyAC 110/220±10% 50~60Hz
Temperature (operating/storage)-20~50°C -40~60°C
Humidity(operating/storage)10%~90%RH 10%~85%RH
MTBF≥1000 Hours
Life Span≥50000 Hours
Pixel Failure<0.0003

Application of HD LED Display:


PASSION LED P1.92 indoor HD LED display is also called HD LED TV as one of the most popular led display used in TV Studio, Entertainment Center, Surveillance Room, Indoor meeting hall. With small cabinet size: 400 x 300mm, Die-casting aluminum structure with high precision and cooling effect.


Our advantages:

1. Rich experience: established in 2007; familiar with technical and material about LED display and LED light.
2. Absolute OEM service: providing the most suitable solution for you according to your different demands (such as quality, price and etc.). At least 3 different types in one material are provided for your choice , and with the lowest-cost custom service.
3. Powerful R&D ability: excellent engineers are constantly developing new products and improving them.
4. Good quality: stable performance .
5. Thoughtful service: we always serve you heart and soul, striving to make our products meet your demands in maximum degree.
6. We guarantee all our LED products for 2 years and provide lifetime maintenance charging only for raw materials. We provide an excellent after-sale service, which contains free training, free CAD drawings, for more convenience and free consultation lifetime, and we will inspect our products which have been sold periodically.
